K Series Amplifier Intended for QSC K8,K10,K12 Powered Speaker W/Bluetooth (220V)

Description

About the Product 🔑

Feature 🌟	Details 📝
Product Name 🏷️	New LASE K Series Professional Loudspeaker Bi-Amped Power-Amplifier Module
Compatibility ✅	Compatible Replacement for QSC K8, K10, K12, KLA12
Unique Control Features ⚙️	Same number of unique control features as the original
Connection Type 🔌	Locking IEC connection for a remote gain control
Note on Fit ⚠️	Does not fit on the K.2
Compatible Models (additional) 🔊	QSC K12, K10, K8, KLA12, KW152, KW153 Powered Speaker
Included Cable ⚡	Power Con Cable Included
Amplifier Protection 🛡️	Thermal Limiting/ Output over current / Over temperature muting
Indicators 💡	Power, Signal A / Signal B / Stand By / Limit / Mic / BT
Model Number 🔢	220V
Manufacturer 🏭	LASE
ASIN 🆔	B0DH5YNNY5
Country of Origin 🇨🇳	China
Controls 🎛️	Power – Gain A; Gain B- Mic/Line. LF Mode – (Ext Sub/Norm/ Ent Sub.). HF Mode – (Vocal/ Boost / Flat.) Front LEDs ( On/Off/Limit).
Cooling System 💨	On Demand 50mm Variable speed fan
Transducer Protection 💥	Thermal Limiting / Excursion Limiting
Power Output 🔋	1000 W continuous Class D (500 W LF, 500 W HF), 2000 W peak
Frequency Response 📈	48 Hz – 20 kHz
Crossover Frequency 🎚️	1.7 Khz
THD (Total Harmonic Distortion) 🎶	20 Hz – 20 kHz for 1 W <0.1%
Signal-to-Noise Ratio 📊	>112 dBA
Channel Separation (Crosstalk) 🔇	at 1 kHz >70 dB
Input Connectors 📥	Balance Female XLR/1/4″ Line/Mic. Stereo RCA Line Level Input
Output Connector 📤	Dual Balanced male XLR Full range line level out / Balanced Male XLR ” Mix Out”.
Class 🎓	TD
Operating Voltage ⚡	110 V / 220 V nominal 190-240 V / 90-130 V selectable

How to Use 🛠️

• The New LASE K Series BT Professional Loudspeaker Bi-Amped Power-Amplifier Module, This Compatible Replacement for QSC K8, K10, K12, KLA12 has same number of unique control features as the original plus locking IEC connection for a remote gain control. Please note that this item does not fit on the K.2 .

Product Details 🏷️

Price: [price_with_discount]

(as of [price_update_date] – Details)

LASE Replacement Amplifier K Series Module w/ BlueTooth for QSC K12, K10, K8, KLA12, KW152, KW153 Powered Speaker.(Power Con Cable Included) Very Easy To Install. The New LASE K Series BT Professional Loudspeaker Bi-Amped Power-Amplifier Module, This Compatible Replacement for QSC K8, K10, K12, KLA12 has same number of unique control features as the original plus locking IEC connection for a remote gain control. Please note that this item does not fit on the K.2 Series.

Product Dimensions ‏ : ‏ 14 x 7.5 x 4.5 inches

Item model number ‏ : ‏ 220V

Date First Available ‏ : ‏ September 16, 2024

Manufacturer ‏ : ‏ LASE

ASIN ‏ : ‏ B0DH5YNNY5

Country of Origin ‏ : ‏ China

Controls : Power – Gain A; Gain B- Mic/Line. LF Mode – (Ext Sub/Norm/ Ent Sub.). HF Mode – (Vocal/ Boost / Flat.) Front LEDs ( On/Off/Limit). Indicators : Power, Signal A / Signal B / Stand By / Limit / Mic / BT Cooling : On Demand 50mm Variable speed fan. Amplifier Protection :Thermal Limiting/ Output over current / Over temperature muting.

Transducer Protection : Thermal Limiting / Excursion Limiting. Power Output :1000 W continuous Class D (500 W LF, 500 W HF), 2000 W peak Frequency Response(+o/-0.3dB,1W/8Ω) : 48 Hz – 20 kHz Crossover Frequency : 1.7 Khz

THD : 20 Hz – 20 kHz for 1 W <0.1% Signal-to-Noise Ratio : >112 dBA Channel separation : (Crosstalk) at 1 kHz >70 dB

Input Connectors (per channel) : Balance Female XLR/1/4″ Line/Mic. Stereo RCA Line Level Input Output Connector: Dual Balanced male XLR Full range line level out / Balanced Male XLR ” Mix Out”. Remote Gain Control, locking IEC power connector Class : TD Operating voltage : 110 V / 220 V nominal 190-240 V / 90-130 V selectable

Full Images

Product Standout Benefits

Performance and Control

This replacement amplifier module offers a range of controls for precise audio management.

• Gain A; Gain B: Mic/Line controls allow for adjustment of input signal levels.
• LF Mode: Options include Ext Sub, Norm, and Ent Sub for Low-Frequency adjustments.
• HF Mode: Select from Vocal, Boost, or Flat settings for High-Frequency tuning.
• Front LEDs: Indicators for On/Off and Limit provide visual feedback on the unit’s status.
• Indicators: Comprehensive indicators for Power, Signal A, Signal B, Stand By, Limit, Mic, and Bluetooth provide real-time operational status.

Amplifier and Transducer Protection

Engineered with robust protection systems to ensure longevity and reliable operation.

• Amplifier Protection: Features include Thermal Limiting, Output Overcurrent, and Over-temperature Muting to safeguard the amplifier.
• Transducer Protection: Thermal Limiting and Excursion Limiting protect the speaker drivers from damage.

Power and Specifications

Delivers powerful and clean audio output with high-quality specifications.

• Power Output: 1000 W continuous Class D (500 W LF, 500 W HF), with a 2000 W peak output.
• Frequency Response: A wide 48 Hz – 20 kHz response ensures full-range sound reproduction.
• Crossover Frequency: Set at 1.7 kHz for effective separation of low and high frequencies.
• THD: Less than 0.1% THD from 20 Hz to 20 kHz for 1 W, ensuring audio clarity.
• Signal-to-Noise Ratio: Greater than 112 dBA for a clean and noise-free signal.
• Channel Separation: Greater than 70 dB crosstalk at 1 kHz, ensuring minimal interference between channels.

Connectivity and Installation

Designed for easy integration and versatile connection options.

• Input Connectors: Balanced Female XLR/1/4″ Line/Mic and Stereo RCA Line Level Input provide flexible input options.
• Output Connector: Dual Balanced Male XLR Full range line level out and Balanced Male XLR “Mix Out” for signal chaining.
• Remote Gain Control: A locking IEC power connector supports remote gain control.
• Easy to Install: The module is very easy to install.

Advanced Features

Includes modern features for enhanced functionality.

• Bluetooth: Built-in Bluetooth connectivity for wireless audio streaming.
• Cooling: An on-demand 50mm variable speed fan ensures optimal operating temperature.

Customer Questions and Answers

Q: How do I install this replacement amplifier module? 🤔

It’s super easy to install! Just follow the steps and you’ll have it up and running in no time. ✨

Q: Is this amplifier module compatible with my QSC speaker? 🌿

This module is a compatible replacement for QSC K8, K10, K12, and KLA12 models. It features the same number of unique control features as the original, plus a locking IEC connection for remote gain control. Please note that this item does not fit on the K.2 Series. 💡

Q: What kind of audio controls does it have? 🔊

You get a great range of controls! There’s Power (Gain A; Gain B) for Mic/Line, LF Mode (Ext Sub/Norm/Ent Sub), and HF Mode (Vocal/Boost/Flat). Plus, front LEDs show On/Off/Limit status. 🔥

Q: Does it have protection features to keep my speaker safe? 🛡️

Absolutely! It’s built with robust protection. You’ve got Amplifier Protection with Thermal Limiting, Output Overcurrent, and Over-temperature Muting. Plus, Transducer Protection includes Thermal Limiting and Excursion Limiting to keep things running smoothly. 🌟

Q: Can I connect it wirelessly? 🎶

Yes, you can! It comes with Bluetooth, so you can easily stream your audio wirelessly. 💻

Q: What are the power specifications? ⚡

It packs a punch with 1000 W continuous Class D power (500 W LF, 500 W HF) and a 2000 W peak output. The frequency response is a wide 48 Hz – 20 kHz, and the crossover frequency is at 1.7 kHz. It also boasts a signal-to-noise ratio of over 112 dBA. 💪
